Channels gone black on 19.2°E

linesman66

TK Veteran
TK Supporter
Maybe you should ignore the 0b01 caid
It might be causing you problems and prioritise the 1884 caid

This is talks solution
Oscam config to get skyde 098D working you need to do this in the oscam config in the Oscam STB Reciever BOX ONLY

[global]
logfile = /tmp/oscam.log
clienttimeout = 12000
fallbacktimeout = 3000
bindwait = 60
netprio = 1
nice = -20
maxlogsize = 1024
waitforcards_extra_delay = 200
preferlocalcards = 1
usrfile = /tmp/oscamuser.log
cwlogdir = /tmp/cw
readerrestartseconds = 1
dropdups = 1
block_same_ip = 0
block_same_name = 0
lb_nbest_readers = 6
lb_nfb_readers = 6
ecmfmt = P: c:0p:s:d:i #ECM_L:l #CW=w HOP:j
failbantime = 1440
failbancount = 2
disablecrccws_only_for = 0500:030B00,032830,050F00;098C:000000;098D:000000;09C4:000000;1708:000000;1811:003311;0E00:000000;092B:000000;1884:000000;1813:000068;0B01:000000

[cache]
cw_cache_memory = 8
cw_cache_settings = 0:2:4000
wait_time = 098D:300
cacheex_lg_only_tab = 098D:000000
cacheex_lg_only_in_tab = 098D:000000
cacheex_ecm_filter_aio = 098D
csp_allow_request = 0
cacheex_cw_check = 0:0:1
wait_until_ctimeout = 1
cacheex_nopushafter = 09:800
waittime_block_start = 5
waittime_block_time = 60
cwcycle_maxlist = 4000
cwcycle_dropold = 0
cwcycle_usecwcfromce = 1

================================================
Next we do this in the Oscam.sevices file:

[64-bit]
disablecrccws_only_for_exception= 0
no_wait_time = 0
lg_only_exception = 1
caid = 098D
provid =
srvid = 00A8,0192,0018,001B,001C,0206,0016,0013,0017,0031,001C,0194,0191,007F,0085,0082,66FB,007C,0076,0070,0089,007E,007B,0065,0093,0080,0088,0071,0075,006E,000A,002B,0009,0008,0204,0029,0196,0197,0083,0087,0074,006B,006F,000B,008B,008C,00DD,00DE,0107,0111,011B,0125,012F,0139,0143,014D,00FD,001E,0145,0150,00FF,006D,0011,0081,0072,010C,0116,0120,012A,0134,013E,0148,0152,0102,017D,0182,0187,010E,0118,0122,012C,0136,0140,014A,0154,0104,008F,0149,0153,0103,0149,0153,0103,0229,00DF,0106,0110,011A,0124,012E,0138,0142,014C,00FC,0069,010B,0115,011F,0129,0133,013D,0147,0151,0101,0228,0201,0159,0163,016D,000D,000E

[dazn]
disablecrccws_only_for_exception= 0
no_wait_time = 0
lg_only_exception = 0
caid = 098D
provid =
srvid = 0084,007A

=================================
Next we now use the oscam.dvbapi and we need to do this:

#Oscam dvbapi list#
#
D: 1830 320
D: 098C 120
D: 098D 120
D: 098E 120
#
P: 098D:000000 1
P: 1830:000000 1

Remove this if you have it in the oscam.dvbapi file: P: 09C4:000000 1 OR do this: I: 09C4:000000 1

The rest of the oscam.dvbapi can be left as you like to use it.
Mine seemed to be working ok without any changes but now has gone back to not working or glitching.
so i decided to try updating my files.
I've changed my config as above.
i cannot find the services file?, i've got a CONF file, BAK file, DVBAPI file, SERVER file and a USER file.
I've also added as above to the DVBAPI file, though not sure if its right.
I changed the DVBAPI file to try to get Canal working on 13e, it's still not great, it went from not working, to working sometimes.
If i add the CONF file and the DVBAPI file here could you possibly take a quick look and see if it looks ok?
thanks.


linesman66

TK Veteran
TK Supporter
Updates for 19.2 east

Astra 1M, 19.2°E



Sky Deutschland: A new channel has started in DVB-S2 VideoGuard: Sky 007 HD Germany (Germany) on 11992.50MHz, pol.H SR:27500 FEC:9/10 SID:111 PID:255[MPEG-4]
/259
German,260
English.

Sky Deutschland: Sky Cinema Special HD has left 11992.50MHz, pol.H (DVB-S2 SID:111 PID:255[MPEG-4]
/259
German,260
English), it is no longer transmitted by satellite in Europe.


linesman66

TK Veteran
TK Supporter
Updated dvbapi
What to Add prioritise Ignore and map

7​
A: ::000A:0104 2600:000000:1FFF ; ERT 1
8​
A: ::0014:0100 2600:000000:1FFF ; ERT 2
9​
A: ::0028:0102 2600:000000:1FFF ; ERT 1 HD
10​
A: ::0001:0100 2600:000000:1FFF ; ERT 2 HD
11​
A: ::0002:0101 2600:000000:1FFF ; ERT 3 HD
12​
13​
14​
###Ignore###
15​
I: 170A:000000 ;OSN
16​
I: 170B:000000 ;OSN
17​
I: 0690:000000 ;Orange Sk
18​
I: 0100:003315 ;csat seca
19​
I: 0100:003311 ;csat seca
20​
I: 0500:032A00 ;Orange Polska
21​
I: 0952:000000 ;Telekom Romania
22​
I: 06F8:000000 ;D-SMART
23​
I: 1708:000000:02C2 ;Aflam 1
24​
I: 1708:000000:02C4 ;Aflam 2
25​
I: 1708:000000:02C5 ;Cinema
26​
I: 1708:000000:030C ;Hekayat Kaman HD
27​
I: 1708:000000:02BF ;Hekayat
28​
I: 1708:000000:02C1 ;Hekayat2
29​
I: 1709:000000:02C2 ;Aflam 1
30​
I: 1709:000000:02C4 ;Aflam 2
31​
I: 1709:000000:02C5 ;Cinema
32​
I: 1709:000000:02BF ;Hekayat
33​
I: 1709:000000:02C1 ;Hekayat2
34​
I: 1709:000000:030C ;Hekayat Kaman HD
35​
I: 0500:23800,40810:4331 ;SRF 1 HD
36​
I: 0500:23800,40810:4332 ;SRF zwei HD
37​
I: 0500:23800,40810:4333 ;RTS Un HD
38​
I: 0500:23800,40810:4334 ;RTS Deux HD
39​
I: 0500:23800,40810:4335 ;Test17205
40​
I: 0500:23800,40810:36E3 ;RSI La 1 HD
41​
I: 0500:23800,40810:36E4 ;RSI La 2 HD
42​
I: 0500:23800,40810:1260 ;3+ Schweiz
43​
I: 5604:000000:0066 ;AFN|prime Atlantic
44​
I: 5604:000000:0067 ;AFN|news
45​
I: 5604:000000:0068 ;AFN|sports
46​
I: 5604:000000:0069 ;AFN|prime Pacific
47​
I: 5604:000000:006A ;AFN|spectrum
48​
I: 5604:000000:006B ;AFN|sports 2
49​
I: 5604:000000:006C ;AFN|family
50​
I: 5604:000000:006D ;AFN|movie
51​
I: 5604:000000:0192 ;AFN|Bars;Tone
52​
I: 5604:000000:0191 ;AFN|Reaper (EPG Video)
53​
I: 0100:003317
54​
I: 0500:032940
55​
I: 0500:032920
56​
I: 0500:043330
57​
I: 0500:040f40
58​
I: 1863:003342
59​
I: 06ED:000000
60​
I: 0500:043800
61​
I: 0100:00006D
62​
I: 093B:000000
63​
I: 1702:000000
64​
I: 1722:000000
65​
I: 1833:000000
66​
I: 1834:000000
67​
I: 0961:000000
68​
I: 0d05:000000
69​
I: 0500:041700
70​
I: 1815:000000
71​
72​
## skyit ##
73​
P: 09CD:000000
74​
P: 0919:000000
75​
76​
77​
78​
### NEOSAT - POLARIS ####
79​
M: 4AEE:000001 4AEE:000000; #1
80​
M: 4AEE:000002 4AEE:000000; #2
81​
M: 4AEE:000003 4AEE:000000; #3

82​
M: 5581:000000 4AEE:000000; #4
83​
P: 4AEE:000000 ;POLARiS 1.9°E
84​
85​
### ADD ###
86​
A: ::000A:0104::: 2600:000000:1FFF ; ERT 1 (39.0E)
87​
A: ::0014:0100::: 2600:000000:1FFF ; ERT 2 (39.0E)
88​
A: ::0028:0102::: 2600:000000:1FFF ; ERT 1 HD (39.0E)
89​
A: ::0001:0030::: 2600:000000:1FFF ; ERT 2 HD (39.0E)
90​
A: ::0001:0100::: 2600:000000:1FFF ; ERT 2 HD (39.0E)
91​
A: ::0002:0101::: 2600:000000:1FFF ; ERT 3 HD (39.0E)
92​
93​
### Emu_key ###
94​
P: 0E00:000000 ;PowerVu
95​
P: 2600:000000 ;BISS
96​
P: 2610:000000 ;BISS2
97​
P: 1010:000000 ;TANDBERG
98​
99​
### POLARiS ####
100​
M: 4AEE:000001 4AEE:000000; #1
101​
M: 4AEE:000002 4AEE:000000; #2
102​
M: 4AEE:000003 4AEE:000000; #3
103​
M: 5581:000000 4AEE:000000; #4
104​
P: 4AEE:000000 ;POLARiS 1.9°E
105​
106​
### polsat ####
107​
P: 0B01:000000
108​
P: 1803:000000
109​
P: 1884:000000
110​
P: 1813:000000
111​
P: 1861:000000
112​
113​
### Priority ####
114​
P: 0500:051A00,051A10,051A40,041200
115​
P: 183E:000000
116​
P: 183d:000000
117​
118​
# Bistv 13E 19E
119​
P: 0500:042820
120​
I: 0500:042800
121​
122​
123​
# Telekom TV 39.0°E
124​
P: 092F:000000
125​
I: 0952:000000
126​
127​
# Total Tv
128​
P: 091F:000000
129​
130​
# Csat
131​
P: 1811:003311
132​
P: 1883:000000
133​
134​
# Movistar+
135​
P: 1810:000000
136​
137​
138​
### A1 BROADCASTING ####
139​
P: 0609:000000
140​
141​
### DIGITALB CD Antiksat Kabelkiosk ####
142​
P: 0B00:000000
143​
144​
### TH-T MAX TV ####
145​
P: 1830:000000
146​
P: 1843:000000
147​
P: 1860:000000
148​
149​
### ORF ####
150​
P: 0648:000000
151​
P: 0D98:000000
152​
P: 0D98:000004
153​
P: 0D98:000010
154​
P: 0d95:000004
155​
156​
### SKY DE ####
157​
P: 09C4:000000
158​
P: 098C:000000
159​
P: 098D:000000
160​
161​
### VIVACOM ####
162​
P: 09BD:000000
163​
164​
### TNTSAT ####
165​
P: 0500:030B00
166​
167​
### DSMART ####
168​
P: 092B:000000
169​
170​
### HTB+ ####
171​
P: 0500:060C00,050C00
172​
173​
### M7 ####
174​
P: 0D97:000004
175​
P: 0D96:000004
176​
P: 0624:000000
177​
178​
# Cdnl #
179​
P: 0100:00006A
180​
P: 1817:00006C
181​
182​
# tvvlaanderen #
183​
P: 0100:00006C
184​
P: 1818:00006C
185​
186​
# skyuk #
187​
P: 0963:000000
188​
189​
# sky ireland #
190​
P: 0960:000000
191​
192​
# Art Nova #
193​
P: 0604:000000
194​
195​
# Viasat #
196​
P: 090F:000000
197​
P: 093E:000000
198​
P: 0940:000000
199​
200​
# Digitv Tvcabo Meo
201​
P: 1802:000000
202​
P: 1880:000000
203​
P: 1814:000000
204​
P: 0100:005221
205​
206​
P: 0500:041950,041960 ;FRANSAT
207​
P: 0500:050800 ;SRG SSR
208​
P: 0500:060200 ;SRG SSR2
209​
P: 0930:000000 ;Yes
210​
P: 090D:000000 ;Yes
211​
P: 2600:000000 ;BISS
212​
P: 0E00:000000 ;PowerVu
213​
P: 1010:000000 ;TANDBERG
214​
P: 0100:000068 ; Nc+ seca
215​
P: 0500:030A00,020A00 ; hrt
216​
P: 0500:031000 ; slotv
217​
P: 0500:041F00,051200 ; Esp
218​
P: 0500:042300,022A00
219​
P: 0500:060A00,060C00,050C00 ; Ntv+
220​
P: 0500:042620 ; luxe tv
221​
P: 0500:051100 ; televisa mexico
222​
P: 0629:000000 ; Pink tv
223​
P: 0B1D:000000 ; mtva Hungarian 9E
224​
P: 0606:000000 ; Albanicsat 16E
225​
P: 0B02:000000 ; focussat
226​
P: 1838:000000 ; unitymedia
227​
P: 09AA:000000 ; Airtel 108E
228​
P: 1819:00006D ; T
elesat
229​
P: 1805:000000 ; Mediaset 5W
230​
231​




prit224

Newbie
Hi Guys, my Uk line is fine and my Euro line is fine. For some reason when watching sky germany the cam keeps connecting to my UK line which causes glitching. If i turn the UK line off in readder this doesnt happen and its smooth. Is there any setting i can change to stop oscam trying to connect to my UK line when im watching sky germany?


Willo3092

VIP Member
You can put a services line in the reader in your oscam.server
I haven't used it for a long time as I've haven't had a decent uk line for yonks.
The '!' means don't use in this reader ...... I think :unsure:

Code:
services                      = sky_deutchland,!sky_digital_(uk)
lb_whitelist_services         = sky_deutchland

Last edited:
